HT PVCHECKs-PRO User Manual

PVCHECKs-PRO
EN - 8
4.2. KEYBOARD DESCRIPTION
The keyboard includes the following keys:
ON/OFF key to switch on/off the instrument
ESC key to exit the selected menu without confirming
MENU key to go back to the instrument's general menu at any time
Keys     to move the cursor within the various screens in order to select
programming parameters
SAVE/ENTER key to save internal parameters and the results of measurements
(
SAVE
)
and to select the desired functions from the menu
(
ENTER
)
GO key to start measuring
STOP key to stop measuring
HELP key to access the help on line and display, for each selected function, possible
connections between the instrument and the system
Ke
y
(
lon
g
pressin
g
)
to ad
j
ust the displa
y
's backli
g
ht
4.3. INITIAL SCREEN
When switching on the instrument, the initial screen appears
for a few seconds. It shows:
 The instrument model (PVCHECKs-PRO)
 The manufacturer’s name
 The serial number (SN:) of the instrument
 The hardware (HW) and firmware (FW) version in the
instrument’s memory
 The date of the last instrument calibration (Calibration
date:)
PVCHECKs-PRO
HT ITALIA
SN: 23020002
HW: 1.00
FW: 1.01
Calibration date:
14/02/2023
After a few seconds, the instrument switches to the last function selected.
