PVCHECKs-PRO
EN - 22
6.3.4. Anomalous situations
1. To zero the value of compensated resistance, carry out a
new compensation procedure with a resistance higher
than 5 as, for example, with open leads. The message
“Zero Reset” appears on the display.
RPE 15/10 – 18:04
R - - -
Itest - - - mA
Zero Reset
STD 2.00 - - -
MODE Lim.
><
2. In case the instrument detects a voltage higher than 3V
at its terminals E and C, it does not carry out the test,
gives out a long sound and displays the message “V.Input
> 3V”.
RPE 15/10 – 18:04
R - - -
Itest - - - mA
V.Input > 3V
STD 2.00 - - -
MODE Lim.
><
3. In case the instrument detects that the calibrated
resistance is higher that the measured resistance, the
instrument gives out a long sound and displays the
message: “Zeroing NO OK”
RPE 15/10 – 18:04
R 0.03
Itest 212 mA
Zeroing NO OK
STD 2.00 0.220
MODE Lim.
><
4. In case the instrument detects a resistance higher than
5 at its terminals, it gives out a long sound, zeroes the
compensated value and displays the message “Zero
Reset”.
RPE 15/10 – 18:04
R >4.99
Itest 49 mA
Zero Reset
STD 2.00 - - -
MODE Lim.
><
5. In case it was detected that the calibrated resistance is
higher than the measured resistance (for example
because cables different from the provided ones were
used), the instrument gives a long acoustic signal and
displays a screen similar to the one to the side. Carry out
a reset and make a new compensation of the cables.
RPE 15/10 – 18:04
R - - -
Itest - - - mA
Rcal > Rmeas
STD 2.00 - - -
MODE Lim.
><
