PVCHECKs-PRO
EN - 10
5.1.2. Date and time
Move the cursor to Date and time by using the arrow keys
(,) and confirm with ENTER. Subsequently, the screen to
the side appears, so that the system’s date/time can be set.
Select “Format” to set the European (“DD/MM/YY, hh:mm”
EU) or American (“MM/DD/YY hh:mm” USA) format. Select
the desired option by using the arrow keys (,) and (, ).
Press the ENTER key to confirm or the ESC key to go back to
the previous screen.
SET
15/10 – 18:04
Format
:
EU
Year
:
19
Month
: 10
Da
: 14
Hour
:
17
Minute :
38
5.1.3. General settings
Move the cursor to General settings by using the arrow keys
(,) and confirm with ENTER. The instrument shows the
screen in which it is possible to enable/disable the auto power
off function, key sound, display contrast and WiFi connection
(see § 8)
Select the desired option by using the arrow keys (,).
Press the ENTER key to confirm or the ESC key to go back to
the previous screen.
SET
15/10 – 18:04
utoPowerOff
:
OFF
Ke
sound
:
OFF
Contrast
: 50
WiFi
: OFF
5.1.4. Irradiance
This section allows setting the minimum irradiance threshold for IVCK measurement.
1. Position the cursor onto “Irradiance” by using the arrow
keys (,) and confirm with ENTER.
2. The display shows the screen containing item “Min. Irrad.
[W/m2]”, which allows setting the minimum irradiance
threshold expressed in W/m
2
, used as a reference for
IVCK measurement.
3. To set the minimum irradiance threshold, use the arrow
keys ( , ). The value can be set in a range 100 1000
W/m
2
in steps of 10 W/m
2
4. Press the SAVE key to save the settings made; the
message “Data saved” will be displayed for a few seconds.
Press the ESC/MENU key to exit without saving and go
back to the previous screen.
SET 15/10 – 18:04
Min.Irrad.[W/m2] : 700
Data saved
5.1.5. Info
Move the cursor to Info by using the arrow keys (,) and
confirm with ENTER.
The instrument shows the initial screen as indicated in the
screen to the side. Press the ESC key to go back to the main
menu.
15/10 – 18:04
PVCHECKsPRO
HT ITALIA
SN: 23020002
HW: 1.00
FW: 1.01
Calibration date:
14/02/2023
