5. In case the instrument detects that the voltage between
the positive and the negative pole is higher than the set
test voltage, the message “VPN>Vtest” appears on the
display and the instrument stops the test because it does
not comply with standard IEC/EN62446-1. Check the
rated voltage of the installation, change the parameter
Vtest, if necessary, and repeat the test.
M 15/10 – 18:04
(+) (-)
Vtest 1520 1510 V
Ins.re - - - - - - M
Rp - - - M
VPN VPE VNE
1480V 750V -730V
VPN>Vtest
DUAL 1500V 1.00M
MODE Vtest. Lim.
6. In case the instrument detects that Rp<Lim, the message
“NOT OK” is shown on the display.
M 15/10 – 18:04
(+) (-)
Vtest 1540 1520 V
Ins.re 0.1 >100 M
Rp 0.1 M
VPN VPE VNE
1480V 750V -730V
NOT OK
DUAL 1500V 1.00M
MODE Vtest. Lim.
