PVCHECKs-PRO
EN - 41
N CONDITION RESULT
1
(If ISO measurement selected) Rp ≥ Rp Lim
(If RPE measurement selected) RPEmis ≤ RPELim
OK
2
Previous condition (1) is not verified, but the following one is valid:
(If ISO measurement selected) Rp ≥ Rp Lim
(If RPE measurement selected) RPEmis ≤ RPELim
OK*
3
Previous conditions (1) and (2) are not verified, but the following one is
valid:
(If ISO measurement selected) Rp ≥ Rp Lim
(If RPE measurement selected) RPEmis ≤ RPELim
NO OK*
4 Previous conditions (1), (2) and (3) are not verified NO OK
11. Press the SAVE key to store the test result in the instrument’s memory (see § 7.1) or
the ESC/MENU key to exit the screen without saving and go back to the main
measuring screen.
CAUTION
The average values of Voc and Isc are displayed in the results page. These
values include the average values of Voc and Isc under OPC conditions
calculated as a rolling average of the last 10 tests previously saved. If
the user has carried out and saved a number of tests <10 or reset the
average values, the average value displayed during test N+1 will be
calculated on the available N values.
When using the instrument like this, the average values previously
calculated are particularly important. In case a new measurement campaign
is started with significant variations in irradiance or temperature, it is
advisable to set the average reference values (“RESET”) to zero to make
new calculations based on new measurements. Average values are anyway
zeroed in case the user chan
es the number of modules and/or strin
s.
