69
LP-542 REV. 7.16.15
Figure 55 – Combustion System Replacement Parts
#
DESCRIPTION
PART NUMBER
#
DESCRIPTION
PART NUMBER
46
Burner Inlet Channel (with
Damper)
7855P-367
56
Gas Pipe (to Mixer)
80/100 Model
7855P-377
120/140 Model
7855P-378
46-1
Air Damper
7855P-368
57
¾” Gas Pipe Gasket
7855P-379
46-2
Air Damper Guide
7855P-369
58
Gas Pipe (to Gas Valve)
7855P-380
47
Burner Inlet Channel Gasket
7855P-370
59
Gas Valve Assembly
7855P-381
48
Fan
7855P-025
59-1
Gas Valve Outlet Adapter
7855P-232
49
Fan O-Ring
7855P-371
59-2
Gas Valve O-Ring
7855P-076
50
Mixer
Model
NG
LP
59-3
Gas Valve
7855P-034
80
7855P-300
7855P-301
100
7855P-302
7855P-303
120
7855P-316
7855P-305
140
7855P-317
7855P-307
51
Air Intake Hose Top Clamp
7855P-372
59-4
Gas Valve Inlet Adapter
7855P-033
52
Air Intake Hose
80/100 Model
59-5
Gas Valve Bracket
7855P-234
7855P-373
120/140 Model
7855P-374
53
APS Hose Fitting
7855P-375
60
Gas Inlet Adapter (3/4”)
7855P-382
54
Mixer Clamp
7855P-376
55
½” Gas Pipe Gasket
7855P-221
Table 36 – Combustion System Replacement Parts
