14
LP-542 REV. 7.16.15
The control can be set up to monitor outdoor temperature through an outdoor sensor to regulate boiler set point temperature, increasing
overall system efficiency while providing great comfort. The system can be further enhanced by installing an indirect water heater to
provide domestic hot water.
The control can regulate the output of multiple boilers through its cascade system function by establishing one boiler as the master and
the other connected boilers as followers. The master boiler requires a sensor to provide feedback on set point temperature in order to
adjust heating output from the connected boilers. Through the use of multiple UFT boilers cascaded systems offer greater system
turndown and redundancy.
Electronic LCD Display – The high resolution display allows the user to monitor boiler functions. The display also provides the means
to program the system parameters to maximize the efficiency of the system design.
Combustion System (Blower – Gas Valve – Mixer – Burner – Spark Ignition) – The highly efficient spark ignition combustion system
uses a variable speed blower to adjust combustion as the system requires more or less energy. The negative regulated gas valve
provides only the amount of fuel required to ensure clean combustion. The mixer accurately regulates the combination of gas and air
throughout the modulating range to ensure high reliability. The burner is constructed of durable ceramic metal fiber for long service life.
Boiler Sensors (Return – Supply – Flue - Outdoor) - Sensors provide highly accurate temperature monitoring to assure accurate
system control. These sensor inputs can be monitored through the boiler control system and display.
Pressure Gauge – Allows the user to monitor system pressure.
System Safeties – The boiler is provided with many safety features to ensure reliable and safe operation. Each safety is connected to
the boiler control. The boiler will alert the user if an unsafe condition occurs and needs to be addressed. The following are provided
safeties: Flue Pressure Switch (monitors flue pressure), Burner High Limit (monitors burner plate temperature), High Limit Water Switch
(monitors boiler water temperature), Low Water Sensor (monitors water level in the heat exchanger), optic flame sensor (monitors flame
quality), Flue Sensor (monitors flue temperature), Condensate Pressure Switch (monitors pressure to ensure condensation does not
back up into boiler).
Manual Air Vent – Each boiler is equipped with an air vent to discharge air from the system during start–up.
Intake and Exhaust Adapters – The boiler is equipped with adapters to ease connection to the vent system. The adapters are
provided with clamps and seals to secure field supplied piping, and test ports to ease monitoring of the combustion system. Each boiler
is supplied with a 6 inch piece of CPVC that must be connected into the exhaust vent adapter.
Boiler 1 ¼” Inlet and 1 ¼” Outlet Connection – Boilers are equipped with both top and bottom piping connections for greater
installation flexibility.
Gas Connection – The boiler is equipped with a ¾” gas connection to connect the incoming gas supply.
Field Wiring and Power Switch – Each boiler is supplied with a power switch to cut off power. The boiler is also equipped with two
front mounted terminal strips. These terminal strips are separated into low and line voltage to ease system wiring.
Condensate Trap and Hose Assembly – Each boiler has a built-in condensate trap to control the discharge of condensate produced
by the boiler during normal operation. A corrugated condensate hose is also provided to ensure proper drainage of condensate into the
pump or drain.
Low Water Cut Off Probe – LWCO is provide with each boiler to assure the boiler has adequate water level to eliminate overheating
and even damaging the boiler heat exchanger .
Pump Service Mode – Allows manual operation of pumps to commission system and check pump operation.
PART 4 – PREPARE BOILER LOCATION
A. UNCRATING THE BOILER
UNCRATING BOILER – Any claims for damage or shortage in shipment must be filed immediately against the transportation company
by the consignee.
Cold weather handling – If boiler has been stored in a very cold location (below 0
o
F) before installation, handle with care until the plastic
components come to room temperature.
