HTP UFT-100W User Manual

72
LP-542 REV. 7.16.15
START-UP REPORT
LIGHT OFF ACTIVITIES
DATE COMPLETED ________________
Yes
No
1) Fill the
heating system
Check all piping and gas connections, verify all are tight
Has the system been cleaned and flushed?
Has the boiler and the system been purged of all air? Refer
to Start-Up Preparation, this manual.
Has the auto air purge feature been used / set? Refer to
Start-Up Preparation, this manual.
Pressurize system (12 – 15 psi) CH
____ PSI
Add water to prime condensate cup
Percentage of glycol in system (0 – 50%)
____ %
Verify proper near boiler piping (Primary/Secondary)
2) Electrical
Have the power and control wiring been connected per the
wiring diagram in this manual?
Is the supply voltage 120v and polarity correct?
3) Check gas
pipe
Leak test using locally approved methods (consult
jurisdictional code book)
Has the gas supply line been verified to deliver the required
BTU of the boiler?
Has a union and shut-off valve (no less than ½”) been
installed?
Does the gas type match the type indicated on the rating
plate?
Check incoming gas pressure (3.5” to 14” W.C.)
____ in w.c.
Static
Locate the stickers in the appropriate locations on the boiler
If applicable, have all dip switches been set and verified to
match system requirements?
Verify combustion settings after gas conversion, Carbon
Dioxide
____% CO2
High Fire
____% CO2
Low Fire
Verify combustion settings after gas conversion, Carbon
Monoxide
____ppm
CO
High Fire
____ppm CO
Low Fire
What is the “drop” on light off (No more than 1” W.C.)?
____ in w.c.
Dynamic
4) Venting
Has the boiler been vented with 3” PVC, CPVC,
Polypropylene, or (AL294C) Stainless for Cat IV boilers?
Ensure no ABS or PVC Cellular core has been used
Is the vent sloped upward toward the terminal at a rate of ¼”
per ft. or 2% grade?
Have all intake and exhaust joints been properly sealed and
tested?
Are all vent runs properly supported?
Have the termination screens been installed?
Is the vent termination a min of 12” above grade or the
highest anticipated snow level?
Is the total developed vent length including elbows within
the stated max vent length restriction?
5) Condensate
piping / tubing
Is the condensate line piped with the approved materials
listed in this manual?
Does the condensate line have an air inlet at the top/
beginning of the drain? Refer to Install the Condensate
Drain, this manual.
Has the condensate been piped over to a drain, and
checked to be free flowing?
If necessary, has a condensate pump and /or a neutralizer
been installed?
FINAL
SIGNED BY TECHNICIAN
DATE
