S
N
Cable Connector Installation Position
b PGND cable for the
GPS surge protector
OT terminal (6 mm
2
, M8)
Ground terminal on the GPS
surge protector
OT terminal (6 mm
2
, M4)
Ground terminal in the IMB03
c BBU power cable (in
the DC power supply
scenario)
3V3 power connector Power supply port on the UPEU
OT terminal (1.5 mm
2
, M4)
LOAD6 port on the DCDU-03B
BBU power cable (in
the AC power supply
scenario)
3V3 power connector Power supply port on the UPEU
H4 connector LOAD1 port on the AC/DC
power device
d FE/GE cable RJ-45 connector FE0 port on the LMPT
External transmission equipment
e Input power cable (in
the DC power supply
scenario)
OT terminal (16 mm
2
, M6)
Wiring terminal labeled NEG for
the blue wire of the input power
cable on the DCDU-03B
Wiring terminal labeled RTN for
the black wire of the input power
cable on the DCDU-03B
Connector added on site
Corresponding wiring terminal
on the external DC power
distribution device
Input power cable (in
the AC power supply
scenario)
C13 connector AC INPUT terminal on the AC/
DC power device
Connector satisfying the
actual requirement
AC socket or Power Distribution
Frame (PDF) of the customer
f CPRI Optical Cable DLC connector CPRI port on the LBBP
CPRI_W or CPRI0 port on the
RRU
g GPS clock signal
cable
SMA male connector GPS port on the LMPT
N-type connector GPS surge protector
h FE/GE optical cable LC connector FE1 port on the LMPT
LC connector
FC connector
SC connector
External transmission equipment
DBS3900 (Ver.B)
Installation Guide 13 Indoor Scenario (BBU Installed in an IMB03)
Issue 06 (2011-09-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
485
