CAUTION
Reserve the plastic screws for later use.
Figure 14-11 Installing the lifting lugs
(1) Plastic screw (2) Lifting lug
Step 2 Install ropes on the lifting lugs, and then lift the cabinet, as shown in Figure 2.
DBS3900 (Ver.B)
Installation Guide
14 Indoor Scenario with DC Power Supply (BBU Installed
Indoors and RRU Powered Outdoors)
Issue 06 (2011-09-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
509
