Huawei FusionModule5000 Product Description

FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
104
Figure 3-74 shows an AC actuator.
Figure 3-74 AC actuator
(1) AC OUT2 port
(2) AC OUT1 port
(3) AC IN port
(4) Status indicator
(5) BLINK button
(6) AI/DI dry
contact
(7) COM1–2 RS485
port
Specifications
Table 3-74 lists the AC actuator technical specifications.
Table 3-74 AC actuator technical specifications
Item
Specifications
Power input
One AC input, 90–240 V AC
Power output
Two AC outputs, 90–240 V AC, maximum current 5 A
Wireless
communicatio
n
One wireless communication port, complying with IEEE802.15.4
RS485 port
One route of dual RS485 ports, not isolated (reserved)
AI/DI
detection
One AI/DI dry contact connects to the lighting switch, and the other is
reserved.
