Product Family:
Broadband Access
Product:
SmartAX MA5600
Fault Type:
Backplane/Board Hardware
Keywords: 32-channel
Permission Level: 04Common Users Permission
Phenomenon Descr
iption:
Q:
Is the 32-channel service board slot compatible with the 64-channel service board on the MA5600?
Alarm Informatio
n:
Null
Cause Analysis:
Null
Handling Proces
s:
A:
The heat generated by the 64-channel service board is more than that of the 32-channel service
board, so the power of the fan tray for the 32-channel service board cannot meet the requirements
on the heat dissipation of the 64-channel service board. If the 64-channel service board is installed
in the slot for the 32-channel service board, the 64-channel service board may be faulty. Therefore,
the 32-channel service board is not slot compatible with the 64-channel service board.
Suggestions and
Summary:
The BOM of the fan for the newly delivered shelf is 32030010.
1.22 FAQ-How to Connect and Configure the Humidity Sensor in the H304ESC
Title: FAQ-How to Connect and Configure the Humidity Sensor in the H304ESC
ID: SE0000356394
Information Type :
Troubleshooting Cases
Quality Level:
B
Update Time: 2008-11-10 17:12:42
Views: 16
Author: w56146
Product Family:
Broadband Access
Product:
SmartAX MA5600
Fault Type:
Power System
Keywords: H304ESC, Humidity sensor
Permission Level: 04Common Users Permission
Phenomenon Descr
iption:
Q:
How to connect and configure the humidify sensor in the H304ESC?
Alarm Informatio
n:
None
Cause Analysis:
None
Handling Proces
s:
A:
As for hardware connection, the H304ESC provides many JTD interfaces and JTA interface.
Where, the JTD interface is used for connecting the digital parameter sensor, and the JTA interface
is used for connecting the analog parameter sensor.
In general, the humidity sensor is an analog parameter sensor. Therefore, it can be connected to
the JTA2 interface.
As for software configuration, see the Command Reference of the corresponding device. The
following shows an example of the command.
huawei(config-if-h304esc-0)#esc analog 6 40 80 0 100 sersor-type :1current unit H name
RoomHumidity
