NGN Cases Chapter 3 GPON FTTx Cases
Confidential Information of Huawei. No Spreading without Permission
58
Handling Proces
s:
Change the port and replace the H813e. The fault, however, persists. Check the data
configuration. A multicast VLAN is configured on this port. Delete this multicast VLAN
and then the fault is rectified.
Suggestions and
Summary:
Consult R&D engineers and then find that this restriction exists on the H813e (this
restriction exists on all ONTs with PMC chips). That is, when the PVID of a port of the
H813e is configured to be the same as the multicast VLAN, the port is in the faulty state
and cannot forward packets normally. Therefore, in the similar networking, mitigate this
problem through configurations.
3.20 The ONT Connected to the MA5680T Cannot Receive the Broadcast Packet Due to the
Fault of the ONT
Title:
The ONT Connected to the MA5680T Cannot Receive the Broadcast Packet Due to
the Fault of the ONT
ID: SE0000363353
Information
Type :
Troubleshooting Cases Quality Level:
C
Product Family:
Optical Access
Product:
MA5680T
Fault Type:
ONT terminal
Keywords: Broadcast
Permission
Level:
02Huawei Partners Permission
Phenomenon De
scription:
Networking:
------(0/19/0)5680T(0/0/0)-----813e------
|---------------SmartBits-----------------------|
The SmartBits is used to transmit 100 M broadcast traffic from the upstream port of the
MA5680T to the PON port. The FE port of the ONT, however, cannot receive any traffic.
Alarm Informatio
n:
Null
Cause Analysi
s:
1. The fault may be caused by the data configuration of the upstream port, but the
upstream port can forward the unicast packets. Therefore, the fault is not caused by the
data configuration.
2. The fault may be caused by the broadcast suppression of port 0/19/0. Run the display
traffic-suppress command to query the port, and it is found that although the broadcast
suppression is enabled, the maximum bandwidth is limited to 9265 kbit/s. Therefore, the
ONT can receive certain traffic. Disable the broadcast suppression. It is found that the
ONT cannot receive any traffic, either. The collected data is as follows:
MA5680T(config-if-giu-0/19)#display traffic-suppress 0
Traffic suppression ID definition:
---------------------------------------------------------------------
NO. Min bandwidth(kbps) Max bandwidth(kbps) Package number(pps)
---------------------------------------------------------------------
1 6 145 12
2 12 291 24
3 24 582 48
4 48 1153 95
5 97 2319 191
6 195 4639 382
7 390 9265 763
8 781 18531 1526
9 1562 37063 3052
