T-CONT 0 of the OMCI uses DBA profile 1 by default.
MA5600T(config)#dba-profile add type2 assure 1024
If the bandwidth and type of T-CONT 0 for the OMCI need to be changed on the
MA5600T of R52, a DBA profile needs to be added. The type of the T-CONT 0 is
assured and the bandwidth is 1Mbit/s.
MA5600T(config)#display dba-profile all
----------------------------------------------------------------------------
Profile-ID type Bandwidth Fix Assure Max Bind
compensation (kbps) (kbps) (kbps) times
----------------------------------------------------------------------------
1 1 No 5120 0 0 1
2 1 No 1024 0 0 0
3 4 No 0 0 32768 0
4 1 No 1024000 0 0 0
5 1 No 32768 0 0 0
6 1 No 102400 0 0 0
7 2 No 0 32768 0 0
8 2 No 0 102400 0 0
9 3 No 0 32768 65536 0
10 2 No 0 1024 0 0
----------------------------------------------------------------------------
DBA profile 10 is newly added through query. DBA profiles 1-9 are default profiles. The
OMCI uses DBA profile 1.
The bandwidth and type of T-CONT 0 for the OMCI in slot 13 PON port 0 ONT 0 are
changed.
MA5600T(config-if-gpon-0/13)#tcont modify-profile 0 0 0 profile-id 10
MA5600T(config-if-gpon-0/13)#display ont info 0 0
----------------------------------------------
T-CONT-ID DBA-profile Alloc-ID
----------------------------------------------
0 10 0 ——DBA profile 10 is used.
Suggestions and
Summary:
If 64 ONTs are fully configured on the PON port, 256 Mbit/s (64 x 4) upstream
bandwidths can be released through the preceding operation. This is considerable.
3.9 THE GICF Board Is in the config State and the Service Cannot Recover After the
MA5680T Is Restarted
Title:
THE GICF Board Is in the config State and the Service Cannot Recover After the
MA5680T Is Restarted
ID: SE0000374164
Information
Type :
Troubleshooting Cases Quality Level:
C
Product Family:
Optical Access
Product:
MA5680T
Fault Type:
Backplane/Board Hardware
Keywords: The GICF board is in the config state
Permission
Level:
02Huawei Partners Permission
Phenomenon De
scription:
After the MA5680T is restarted, the GICF board is in the config state and the service
cannot return to the normal state.
The version of the MA5680T is V800R105C33B011.
Alarm Informatio
n:
Null
Cause Analysi
s:
The optical port must be enabled when the GICF board works normally. After the
