Huawei MA5600 - iManager N2000 BMS Cases; Failure in Alarm Displaying on the N2000 BMS Due to the Error of Setting the Source IP Address of the Trap Packets on the MA5680 T

MSAN UA5000 Cases Chapter 6 iManager N2000 BMS Cases
Confidential Information of Huawei. No Spreading without Permission
83
Keywords: Round robin, processing, mechanism
Permission
Level:
04Common Users Permission
Phenomenon De
scription:
Q:
What is the voice subboard round robin mechanism of the PVM board?
Alarm Informati
on:
Null
Cause Analysi
s:
Null
Handling Proce
ss:
A:
TI: This round robin mode allocates 32 successive channels in an ascending order based on the n
units planned inside the subboard. If two units are divided for a subboard, the first allocated is
the DSP channel 0 in the first unit, the next allocated is the DSP channel 0 in the second unit,
still the next allocated is the DSP channel 1 in the first unit, then the DSP channel 1 in the
second unit, and so on.
MIRO: This round robin mode is basically the same as the TI mode except that a unit in this
mode includes 256 successive channels.
Suggestions and
Summary:
Null
Chapter 6 iManager N2000 BMS Cases
6.1 Failure in Alarm Displaying on the N2000 BMS Due to the Error of Setting the Source
IP Address of the Trap Packets on the MA5680T
Title:
Failure in Alarm Displaying on the N2000 BMS Due to the Error of Setting the Source IP
Address of the Trap Packets on the MA5680T
ID: SE0000365191
Update Time: 2008-12-23 10:41:48
Author: h93670
Product Family: Access Network Management System Product: iManager N2000 BMS
Fault Type: Element Management
Keywords: Alarm, trap, source
Phenomenon De
scription:
The BMS version is N2000 BMS V200R011C16B020CP001.
The NE version is MA5680T V800R105C33B011.
Networking: The MA5680T connects to the N2000 BMS through the MEth interface, and then
communicates with the N2000 BMS in the upstream direction through the inband GICF board.
The MA5680T can be managed on the N2000 BMS normally, but the alarms of the MA5680T
fail to be displayed.
Alarm Informat
ion:
Null
Cause Analysi
s:
If the source IP address of the trap packets configured on the NE is different from that of the
interface for connecting the MA5680T to the N2000 BMS, the alarms cannot be reported to the
N2000 BMS.
Handling Proce
ss:
1. Check the source IP address of the trap packets configured on the device. The source IP
address is displayed as METH 0.
