MSAN UA5000 Cases Chapter 3 GPON FTTx Cases
Confidential Information of Huawei. No Spreading without Permission
45
ID: SE0000367153
Information
Type :
Troubleshooting Cases Quality Level:
C
Product Family:
Optical Access
Product:
MA5680T
Fault Type:
Host/Network Management System (independent from service)
Keywords: Mirror
Permission
Level:
04Common Users Permission
Phenomenon De
scription:
Q:
How to perform inter-board mirroring on the upstream board on the MA5680T?
Alarm Informatio
n:
Null
Cause Analysi
s:
Null
Handling Proces
s:
A:
You can use the stream mirror mode. For example, mirror the traffic of port 0/19/0 to
0/20/0:
MA5680T(config-acl-link-4000)#rule 5 permit destination
{ mac_addr<P><XXXX-XXXX-XXXX> }:0000-0000-0000
{ mac_addr<P><XXXX-XXXX-XXXX> }:ffff-ffff-ffff
{ <cr>|type<K>|cos<K>|source<K>|time-range<K> }:
/////Create a link layer rule that is applicable to all packets.//////
MA5680T(config-acl-link-4000)#quit
MA5680T(config)#traffic-mirror
{ inbound<K>|outbound<K> }:outbound
{ user-group<K>|ip-group<K>|link-group<K> }:link-group
{ integer<U><4000,4999> }:4000
{ ip-group<K>|port<K>|rule<K> }:rule 5
{ ip-group<K>|port<K> }:port 0/19/0
{ <cr>|to<K> }:to
{ port<K> }:port 0/20/0
/////////Mirror packets sent from upstream port 0/19/0.///////
MA5680T(config)#traffic-mirror inbound link-group 4000 rule 5 port 0/19/0 to port 0/20/0
//////////Mirror packets sent to upstream port 0/19/0.////////
3.6 FAQ-How to Implement the Interworking Between Different FE Ports on the MA562xG
Title:
FAQ-How to Implement the Interworking Between Different FE Ports on the
MA562xG
ID: SE0000374104
Information
Type :
Troubleshooting Cases Quality Level:
C
Product Family:
Optical Access
Product:
MA5680T
Fault Type:
ONT terminal
Keywords: Interworking
Permission
Level:
04Common Users Permission
