Front Panel Port
xDSL1
(32-63)
LINE0
(0-31)
PSTN1
(32-63)
xDSL0
(0-31)
LINE1
(32-63)
PSTN0
(0-31)
Connected to xDSL port of
the VDSL2 service board
Connected to xDSL port of
the VDSL2 service board
Connected to the MDF
Connected to the MDF
Connected to the MDF
Connected to the MDF
NOTE
Ports on the front panel are concave.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
831
