Huawei SmartAX MA5600T Hardware Description

Board Type Board
Name
One-
channel
Two-fiber
Bi-
directional
GE Optical
Module
One-
channel
One-fiber
Bi-
directional
GE Optical
Module
Two-
channel
One-fiber
Bi-
directional
GE Optical
Module
One-channel
Two-fiber
Bi-
directional
GE CWDM
Optical
Module
GE Electrical
Module
SPU board SPUA/
SPUF
√ √ × √ ×
SPUC √ √ √ √ ×
Ethernet
service
access board
ETHA √ × × × ×
ETHB √ √ × √ √
P2P
interface
board
OPGD/
OPGE
√ √ √ √ √
One-channel Two-fiber Bi-directional GE Optical Module
A one-channel two-fiber bi-directional GE optical module is connected to two LC optical
fibers (one for transmission and the other for reception) to provide one GE channel.
Type
One-channel two-fiber bi-directional optical module
No. 1 2 3 4 5
Operating
Wavelength
850 nm 1310 nm 1310 nm 1550 nm 1550 nm
Encapsulation
Type
eSFP eSFP eSFP eSFP eSFP
Port Rate 2.13 Gbit/s 1.25 Gbit/s 1.25 Gbit/s 1.25 Gbit/s 1.25 Gbit/s
Minimum Output
Optical Power
-9.50 dBm -9.00 dBm -5.00 dBm -5.00 dBm -2.00 dBm
Maximum Output
Optical Power
-2.50 dBm -3.00 dBm 0 dBm 0 dBm 5.00 dBm
Maximum
Receiver
Sensitivity
-17.00 dBm -20.00 dBm -23.00 dBm -22.00 dBm -23.00 dBm
Optical Connector
Type
LC LC LC LC LC
Optical Fiber Type Multi-mode Single-mode Single-mode Single-mode Single-mode
Reach 0.50 km 10.00 km 40.00 km 40.00 km 80.00 km
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
4 Optical and Electrical Module
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
850
