Table 6-25 shows the mapping between the output tributary switches and the loading
tributaries.
Table 6-25 Mapping between the output tributary switches and the loading tributaries
Output Tributary Switch Load Tributary
BATT. BATT. (-) (two channels) and BATT.(+) (two channels)
LOAD1 LOAD1 (-) (two channels) and LOAD1(+) (two
channels)
LOAD2 LOAD2 (-) (two channels) and LOAD2(+) (two
channels)
LOAD3 LOAD3 (-), LOAD3(+)
LOAD4 LOAD4 (-), LOAD4(+)
DIP Switch
The EPS75-4815AF power system provides a DIP switch, the DIP switch is on the right
middle of the monitoring module control board, which can be seen after you remove the
monitoring module. The DIP switch has eight available electrical switches. ON indicates 1,
and OFF indicates 0. Table 6-26 describes the settings of DIP switch.
Table 6-26 Settings of the DIP switch
Electrical
Switch
Setting Indication Factory
Default
1-5 Supported Used to set the address of the environment
monitoring module.
1: OFF
2: OFF
3: OFF
4: OFF
5: OFF
6-7 Supported Used to set the rate of the serial port 6: ON
7: OFF
8 Not
supported
- OFF
The DIP switches 1-5 are used to set the address of the environment monitoring module,
Table 6-27 shows the settings of the DIP switches.
