Table 6-27 Settings of the DIP switches 1-5
5 4 3 2 1 Address Value
0 0 0 0 0 0
0 0 0 0 1 1
0 0 0 1 0 2
0 0 0 1 1 3
0 0 1 0 0 4
0 0 1 0 1 5
0 0 1 1 0 6
0 0 1 1 1 7
0 1 0 0 0 8
0 1 0 0 1 9
0 1 0 1 0 A
0 1 0 1 1 B
0 1 1 0 0 C
0 1 1 0 1 D
0 1 1 1 0 E
0 1 1 1 1 F
1 0 0 0 0 10
... .. .. .. .. ..
The DIP switches 6-7 are used to set the rate of the serial port, Table 6-28 shows the settings
of the DIP switches.
Table 6-28 Settings of the DIP switches 6-7
7
6 Rate Value
0 0 4800 bit/s
0 1 9600 bit/s
1 0 19200 bit/s
Specifications
Table 6-29 lists the specifications of the EPS75-4815AF power system.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
6 Electromechanical Device
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
941
