Huawei Technologies Proprietary
4
z
Power: power switch
z
9V AC 1A: power input plug
Note:
Different adapters are used in according to regions. Make sure your
power adapter is comply with the sign in the rear panel (9V AC 1A or
9V DC 1A).
1.2.3 External Splitter
Using the splitter can reduce disturbance signals in the
telephone line. The MT882 has to use an external splitter, which has
three ports: LINE, PHONE and MODEM.
z
LINE: connect to the telephone jack
z
PHONE: connect to the telephone
z
MODEM: connect to ADSL modem with RJ-11 telephone
line
1.3 MT882 Features
z
Data rates up to 24 Mbps for downstream and 1.2 Mbps for
upstream
z
Friendly Web-Based graphical user interface for
configuration and management
z
Supporting up to eight simultaneous virtual connections
z
Widest range of DSLAM interoperability
z
Built-in MIBs for SNMP management
