Huawei Technologies Proprietary
65
z
Max Host Count: sets the max number of concurrent IP
session that can originate from the computer. This number
should take into account the number of hosts on the LAN.
III. Save
z
Click the Submit button to save the settings in the RAM.
z
To save these configuration changes permanently, enter
the Tools>System Setting page, and then click Save &
Restart button to save new settings.
4.13 RIP
Click the RIP of Advanced in the Wizard Column to set the
rules of firewall. The MT882 supports RIP v1 and RIP v2 used to
share routing tables with other Layer 3 routing devices on your local
network or remote LAN. If your network does not employ another IP
routing device, it will not be necessary to enable RIP.
I. Configuration page
Figure 4-20 RIP Configuration
