Huawei Technologies Proprietary
34
z
WAN Channel: displays the names and settings for the
device WAN interfaces. Multiple software-defined
interfaces may be configured to use the DSL connection.
The PVC number, gateway, IP address, mask, VPI/VCI,
encapsulation and status will be displayed in the WAN
interface.
z
LAN Channel: displays the names and various settings of
LAN interface, which include MAC address, IP address,
Mask, speed, duplex and status.
4.3 WAN Setting
Click the WAN Setting of Home in the wizard column to carry
out the WAN Setting. WAN Setting includes three modes: RFC2684
Bridged, RFC2684 Routed and PPP.
4.3.1 RFC2684 Bridged Connection
Bridged connections include three modes: Pure Bridge, Static
Bridge and DHCP.
z
PVC: system provides 7 PVCs. Generally you can keep
the default value 0. This option is also used to create and
configure new PVCs.
z
VPI: if you need any modification, please enter the VPI
value provided by ISP. See the attached table for all the
VPI default values of PVC.
z
VCI: if you need any modification, please enter the VCI
value provided by ISP. See the attached table for all the
VCI default value of PVC.
z
Encapsulation: you can select LLC or VC MUX.
