Huawei Technologies Proprietary
38
4.3.2 RFC2684 Routed Configuration
I. Configuration page
Figure 4-6 RFC2684 Routed (IPoA) Configuration
II. Parameters eaplanation
z
PVC: the system provides 7 PVCs. Generally you can
leave this set at the default value 0. This option is also used
to create and configure new PVCs.
z
VPI: if you need any modification, please enter the VPI
value provided by ISP. See the attached table for all the
VPI default values of PVCs.
z
VCI: if you need any modification, please enter the VCI
value provided by ISP. See the attached table for all the
VCI default values of PVCs.
z
Encapsulation: you can select the mode LLC or VC MUX.
