Huawei SmartAX MT882 - Applying MT882 LAN IP Address; Inputting User Name and Password

Huawei Technologies Proprietary
29
3.3.1 Checking for Proxy Service
If the browser software on the computer is configured to use a
proxy server for Internet access, it is necessary to first disable the
proxy connection.
In Internet Explorer, you can check whether a proxy server is
enabled using the following procedures:
1) In the Explorer window, select ToolsÆ
ÆÆ
ÆInternet Options to
display Internet Options dialog box.
2) In the Internet Options dialog box, click the Connections
tab and click on the LAN Settings.
3) Make sure the “Use proxy server” option is not checked. If
it is checked, click on the checked box to deselect the
option and click OK.
3.3.2 Applying the LAN IP Address of MT882
To access the Web-based configuration manager, launch your
Web browser and enter the LAN IP address of the MT882. For the
first access, the default LAN IP address of the MT882 is used. Type
in “http://” followed by the default IP address, “192.168.1.1” in the
address bar of the browser. The URL in the address bar should read:
http://192.168.1.1
.
3.3.3 Inputting the User Name and Password
A new dialog box appears prompting you to input the user name
and password required to access the Web-based configuration
manager.
