Huawei Technologies Proprietary
48
I. Configuration page
Figure 4-12 LAN Configuration
II. Parameter explanation
z
IP Address: type in the IP address for the Ethernet LAN
interface. The default IP address is 192.168.1.1
z
Subnet Mask: type in the Subnet Mask for the Ethernet
LAN IP interface. The default mask is 255.255.255.0
z
Local Domain Name: enter the local domain name if it
exists.
Note:
The public IP address that ISP assigned is not LAN IP address. The
public IP address identifies the WAN interface that the ADSL router
connects to Internet.
