Huawei SUN2000-90KTL Series User Manual

Table 5-5 Cable description
No. Cable Type Conductor
Cross-
Sectional Area
Range
Outer
Diameter
Source
1 PE cable Single-core outdoor
copper cable and M8
OT/DT terminal
NOTICE
Preferred to connect to
the PE point on the
enclosure. The PE point
in the maintenance
compartment is used for
connecting to the PE
cable included in the
multi-core AC power
cable.
≥ 16 mm
2
. For
details, see
Table 5-6.
- Prepare
d by the
custome
r
2 RS485
communications
cable (connected to
a terminal block;
recommended)
Recommended: a
multi-paired,
individually foil
shielded cable that
complies with local
standards and M6 OT
terminals
0.25–2 mm
2
14–18 mm Prepare
d by the
custome
r
RS485
communications
cable (connected to
a network port)
Recommended: a CAT
5E outdoor shielded
network cable with the
internal resistance ≤
1.5 ohms/10 m (1.5
ohms/393.70 in.), as
well as a shielded RJ45
connector
- 7–9 mm Prepare
d by the
custome
r
SUN2000-(90KTL, 95KTL, 100KTL, 105KTL) Series
User Manual
5 Electrical Connections
Issue 11 (2020-08-30) Copyright © Huawei Technologies Co., Ltd. 48
