Procedure
Step 1 Determine the hole positions based on the marking-o template, and then mark
the hole positions using a marker.
Figure 4-11 Determining hole positions
Step 2 Drill holes using a hammer drill.
You are advised to apply anti-rust paint on the hole positions for protection.
Figure 4-12 Drilling holes
Step 3 Secure the mounting bracket.
SUN2000-(3KTL-10KTL)-M0
User Manual 4 Installation
Issue 06 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 27
