Figure 4-13 Securing the mounting bracket
Step 4 Install the SUN2000 onto the mounting bracket.
Step 5 Tighten the bolt assembly.
Figure 4-14 Installing the SUN2000
Step 6 (Optional) Install the anti-theft lock.
● Prepare an anti-theft lock suitable for the lock hole diameter (Ф8 mm) by
yourself.
● An outdoor waterproof lock is recommended.
● Keep the key to the anti-theft lock safe.
SUN2000-(3KTL-10KTL)-M0
User Manual 4 Installation
Issue 06 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 28
