Huawei SUN2000-M3 User Manual

D Rapid Shutdown
If all PV modules are equipped with optimizers, the PV system can perform a rapid
shutdown, reducing the output voltage of the optimizers to below 30 V within 30s.
The rapid shutdown is not supported if optimizers are
congured for some PV
modules.
Triggering methods of rapid shutdown:
● Method 1 (recommended): Turn
o the AC switch between the inverter and
the power grid.
● Method 2: Turn
o the DC switch at the bottom of the inverter.
● Method 3: If the DIN5 port (port 15) of the inverter communications terminal
is connected to a rapid shutdown button, press the button to trigger rapid
shutdown.
NO TE
Log in to the FusionSolar App as an installer, choose Me > Device Commissioning,
and connect to the WLAN hotspot of the SUN2000. Log in to the local commissioning
system as an installer user, choose Settings > Feature parameters > Dry contact
function, and set Dry contact function to DI rapid shutdown.
● Method 4: If AFCI is enabled, the inverter automatically detects arc faults,
triggering a rapid shutdown.
SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3
User Manual D Rapid Shutdown
Issue 11 (2023-01-10) Copyright © Huawei Technologies Co., Ltd. 105

Huawei SUN2000-M3 Specifications

General

Type	String Inverter
Rated AC Grid Frequency	50 Hz / 60 Hz
DC Connection Type	MC4
Protection Degree	IP65
Cooling Method	Natural convection
Category	Inverter
Adjustable Power Factor Range	0.8 leading - 0.8 lagging
Total Harmonic Distortion (THD)	≤ 3 %
Operating Temperature Range	-25°C to 60°C
Communication	RS485
Efficiency	98%
Protection Level	DC reverse polarity protection, AC overcurrent protection, AC short-circuit protection, Overvoltage protection, Insulation monitoring, Residual current monitoring unit, Arc fault detection
