Huawei SUN2000-M3 User Manual

5 Electrical Connections
5.1 Precautions
D ANGER
When exposed to sunlight, the PV arrays supply DC voltage to the SUN2000.
Before connecting cables, ensure that the two DC switches on the SUN2000 are
OFF. Otherwise, the high voltage of the SUN2000 may result in electric shocks.
D ANGER
● It is recommended that the site be equipped with qualied re extinguishing
facilities, such as reghting sands and carbon dioxide re extinguishers.
● Wear insulated gloves and use insulated tools to prevent electric shocks or
short circuits.
WARNING
● The equipment damage caused by incorrect cable connections is beyond the
warranty scope.
● Only
certied electrician can perform electrical terminations.
● Wear proper PPE at all time when terminating cables.
● To prevent poor cable connection due to overstress, it is recommended that the
cables be bent and reserved, and then connected to the appropriate ports.
SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3
User Manual 5 Electrical Connections
Issue 11 (2023-01-10) Copyright © Huawei Technologies Co., Ltd. 33

Huawei SUN2000-M3 Specifications

General

Type	String Inverter
Rated AC Grid Frequency	50 Hz / 60 Hz
DC Connection Type	MC4
Protection Degree	IP65
Cooling Method	Natural convection
Category	Inverter
Adjustable Power Factor Range	0.8 leading - 0.8 lagging
Total Harmonic Distortion (THD)	≤ 3 %
Operating Temperature Range	-25°C to 60°C
Communication	RS485
Efficiency	98%
Protection Level	DC reverse polarity protection, AC overcurrent protection, AC short-circuit protection, Overvoltage protection, Insulation monitoring, Residual current monitoring unit, Arc fault detection
