5.6 (Optional) Installing the Smart Dongle
Procedure
NO TE
The Smart Dongle is not provided in standard conguration.
4G Smart Dongle
NO TICE
If your Smart Dongle is not equipped with a SIM card, prepare a standard
SIM card (size: 25 mm x 15 mm) with the capacity greater than or equal to
64 KB.
When installing the SIM card, determine its installation direction based on
the silk screen and arrow on the card slot.
Press the SIM card in place to lock it, indicating that the SIM card is
correctly installed.
When removing the SIM card, push it inwards to eject it.
When reinstalling the cover of the Smart Dongle, ensure that the buckle
springs back in place.
Figure 5-15 Installing a 4G Smart Dongle
WLAN-FE Smart Dongle (WLAN Communication)
SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3
User Manual 5 Electrical Connections
Issue 11 (2023-01-10) Copyright © Huawei Technologies Co., Ltd. 49
