Huawei SUN2000-M3 User Manual

Technical
Specications
SUN2000-20K
TL-M3
SUN2000-29.
9KTL-M3
SUN2000-30K
TL-M3
SUN2000-36K
TL-M3
SUN2000-40K
TL-M3
MPP voltage
range
200–750 V 200–1000 V
Full power
MPPT voltage
range
300–550 V 500–800
V/400 V AC
625–850
V/480 V AC
500–800 V/
(380 V AC,
400 V AC)
625–850
V/440 V AC
625–850
V/480 V AC
520–800 V/
(380 V AC,
400 V AC)
625–850
V/440 V AC
625–850
V/480 V AC
540–800 V/
(380 V AC,
400 V AC)
625–850
V/440 V AC
625–850
V/480 V AC
Rated input
voltage
350 V 600 V (400 V
AC)
720 V (480 V
AC)
600 V (380 V
AC, 400 V AC)
650 V (440 V
AC)
720 V (480 V
AC)
600 V (380 V
AC, 400 V AC)
650 V (440 V
AC)
720 V (480 V
AC)
600 V (380 V
AC, 400 V AC)
650 V (440 V
AC)
720 V (480 V
AC)
Maximum
number of
inputs
8
Number of
MPPTs
4
Note a: The maximum input voltage is the maximum DC input voltage that the SUN2000 can
withstand. If the input voltage exceeds this value, the SUN2000 may be damaged.
Output
Technical
Specications
SUN2000-20K
TL-M3
SUN2000-29.
9KTL-M3
SUN2000-30K
TL-M3
SUN2000-36K
TL-M3
SUN2000-40K
TL-M3
Rated output
power
20,000 W 29,900 W 30,000 W 36,000 W 40,000 W
Maximum
apparent
power
22,000 VA 29,900 VA
33,000 VA
a
40,000 VA 44,000 VA
Maximum
active power
(cosφ = 1)
22,000 W 29,900 W
33,000 W
a
40,000 W 44,000 W
SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3
User Manual 10 Technical Specications
Issue 11 (2023-01-10) Copyright © Huawei Technologies Co., Ltd. 88

Huawei SUN2000-M3 Specifications

General

Type	String Inverter
Rated AC Grid Frequency	50 Hz / 60 Hz
DC Connection Type	MC4
Protection Degree	IP65
Cooling Method	Natural convection
Category	Inverter
Adjustable Power Factor Range	0.8 leading - 0.8 lagging
Total Harmonic Distortion (THD)	≤ 3 %
Operating Temperature Range	-25°C to 60°C
Communication	RS485
Efficiency	98%
Protection Level	DC reverse polarity protection, AC overcurrent protection, AC short-circuit protection, Overvoltage protection, Insulation monitoring, Residual current monitoring unit, Arc fault detection
