Huawei SUN2000L Series User Manual

SUN2000L-(4.125KTL, 4.95KTL)-JP
User Manual
7 Operations on the Local FusionHome App
Issue 03 (2018-04-11)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
101
Parameter
Description
Value Range
Encrypted with
Specifies the encryption
level of the router to which
the inverter WiFi network
connects.
It is related to the network
name.

Not encrypted

WEP_OPEN

WEP_SHARED

WPA

WPA2
Password
Specifies the WiFi password
for the router.
N/A
DHCP

If the IP address
automatically assigned
by the home router is
used, enable this
parameter. Then the
following parameters
will be automatically
assigned.

If the IP address
automatically assigned
by the home router is not
used, disable this
parameter. Then the
following parameters
need to be manually
assigned.

Disable

Enable
IP address
Specifies the IP address for
the router to which the
inverter WiFi network
connects. Recommended:
Set the IP address in the
same network segment as
the home router IP address.
[1.0.0.0, 223.255.255.255]
Subnet mask
Specifies the router subnet
mask.
N/A
Gateway
Specifies the router gateway
address.
N/A
Primary DNS server
Specifies the address for the
primary domain name
service (DNS) server.
N/A
Secondary DNS server
Specifies the address for the
secondary DNS server.
N/A
Setting RS485 Communications Parameters
To set RS485 communications parameters, choose Comm config > RS485 setting from the
Operation console screen.

Huawei SUN2000L Series Specifications

General

Max. DC Voltage	600 V
Max. Efficiency	98.6%
Cooling	Natural Convection
Protection Degree	IP65
Power Output Range	2kW - 5kW
Max. AC Power	5, 500 VA
Rated AC Voltage	220 V / 230 V
European Efficiency	98.2%
Operating Temperature Range	-25°C to +60°C
Weight	10.6 kg
Communication	RS485
