85
Waypoints
NOTE: If the waypoint was marked at the cursor position, select Full Info > Edit Depth. Use the on-screen keyboard to enter a
depth. If you turn on Depth Marker, the depth you enter will be displayed.
Set the Waypoint Radius and Avoidance
A radius can be set around a selected waypoint. If you select Avoidance, the radius will be highlighted around the waypoint. To receive
an alarm when the waypoint avoidance radius has been crossed, turn on the Waypoint Avoidance Alarm (see Navigation Alarms
Overview).
1. Tap the waypoint icon to select it. Tap the Waypoint Name.
OR
Use the Joystick to move the cursor to a waypoint icon. Press the ENTER key.
2. Select Full Info.
3. Select Radius, and turn it on.
Press and hold the slider, or turn the Rotary dial, to adjust the radius setting.
4. To set the waypoint to avoidance, select Avoidance. Tap the check box, or press the ENTER key, to add a check mark to it.
5. Optional: To receive an alarm when the radius has been crossed, turn on Waypoint Avoidance in the Navigation Alarms menu
(Home > Alarms > Navigation > Waypoint Avoidance > On)
Display/Hide a Trolling Grid
The Trolling Grid applies a grid to the Chart View that can be used as a guide when trolling around a speciļ¬c position. The trolling
grid can be applied to any positon on the chart.
1. Tap a position on the Chart View.
OR
Use the Joystick to move the cursor to a position on the Chart View.
2. Tap Chart in the status bar, or press the ENTER key.
3. Select Trolling Grid.
4. Use the menu options to set the grid size and rotation.
Display the Grid: Select Set Grid.
Remove the Grid: Select Remove Grid.
Delete a Waypoint in the Chart View
1. Tap the waypoint icon to select it. Tap the Waypoint Name.
OR
Use the Joystick to move the cursor to a waypoint icon. Press the ENTER key.
2. Select Delete.
