Hunter FLOW-CLIK - Specifications; Flow-Clik Models; Operating Specifications; Additional Features

26
27
Models
Operating Specications
Temperature: 0 to 150 degrees F
Pressures: up to 200 psi
Humidity: up to 100%
Additional Features
Programmable Start Up Delay (0 to 300 seconds)
Programmable Interrupt Period (5 to 60 minutes)
System Status Indicator Light
One Button System Calibration
F L O W R A N G E
FLOW
SENSOR
DIAMETER
OPERATING RANGE (GPM)
MINIMUM*
SUGGESTED MAXI-
MUM**
MAXIMUM
1" 6 17 50
1" 13 35 100
2" 20 55 200
3" 50 120 300
* Minimum recommended ow for the highest ow zone for your system
** Good design practice dictates the maximum ow not to exceed 5ft/sec.
Suggested maximum ow is based upon Class 200 IPS plastic pipe
Electrical Specications
Current Draw: (@ 24 VAC) .025 amps
Switching Current: 2.0 amps
Maximum Distance between Interface Box and Sensor =
1,000 ft.
Dimensions
Flow-Clik Interface Box (4.5"H x 5.5"W x 1.5"D)
Flow-Clik Sensor Body
Model 100 (4.8"H x 2.3"W x 4.5"L)
Model 150 (5.4"H x 2.3"W x 4.6"L)
Model 158 (5.4"H x 2.3"W x 5.1"L)
Model 200 (5.9"H x 2.7"W x 4.7"L)
Model 208 (6.0"H x 2.9"W x 5.4"L)
Model 300 (7.0"H x 4.0"W x 6.2"L)
Model 308 (7.0"H x 4.2"W x 6.4"L)
