Installation Overview
■
Your order will include the correct number of installation brackets for your shade width.
■
Shade orders may also include spacer blocks or extension brackets, if they were specified
for added clearance.
Mounting Types and Window Terminology
If the installation brackets are mounted correctly, the rest of the installation process will
follow easily. To prepare for this important first step, review the mounting types and basic
window terminology illustrated below.
■
Refer to the appropriate page below based on your order:
➤
Inside Mount for Standard/Designer Metal Bracket Shades — Page 4
➤
Outside Mount for Standard/Designer Metal Bracket Shades — Page 5
➤
Inside Mount for Cassette Shades — Page 7
➤
Outside Mount for Cassette Shades — Page 9
Cassette
Installation Bracket
For Added Clearance
Extension
Bracket*
1
∕ 4 " or
1
∕ 2 "
Spacer Blocks*
Standard/Designer Metal
Installation Bracket
*For cassette installation only.
Outside Mount
Shade mounts
outside window
opening.
Inside Mount
Shade fits within
window opening.
Collectively, the sill and
jambs are called the
“window casement.”
Molding
Head Jamb
Sill
Jamb Jamb
