INSTALLATION — STANDARD OR CASSETTE
7
Install the Bracket Cover — Outside Mount Standard Brackets Only
■
Install the idle-side bracket cover by aligning the bracket with the channels in the bracket
cover and sliding it onto the bracket.
■
Install the clutch-side bracket cover by snapping it onto the bracket.
Proceed to “Attach the Universal Cord Tensioner (UCT)” on page 12.
Mount the Brackets — Cassette Inside Mount
■
Your order will include the correct number of installation brackets for your shade width, as
shown in the table below.
Prepare the Installation Brackets
■
Use pliers or heavy duty scissors to remove the top
tabs on the installation brackets.
NOTE: Save these tabs once removed. They may be
used as shims, if necessary.
Mount the Installation Brackets
■
Mark 2" to 3" from each jamb for bracket location.
➤
If more than two installation brackets came with your order, space additional bracket(s)
evenly between the two end brackets and mark their location. Mount into wood
whenever possible.
NOTE: Before the headrail is installed, the bracket levers need to be fully to the left, and
once the headrail is properly in place, levers automatically click to the right.
Slide onto
Bracket
Idle
Clutch
Snap onto Bracket
Installation Brackets For Added Clearance
Extension
Bracket
1
∕
4
" or
1
∕
2
"
Spacer Blocks
Shade Width Brackets
2
3
4
15" – 36"
36
1
∕
8
" – 79"
79
1
∕
8
" – 96"
Tab
Remove Tab
Back Cover Bracket
Bracket Lever
Space Evenly
Space Evenly
2" to 3"
2" to 3"
Jamb Jamb
