VM Series Maintenance and Safety Manual 704-0212-209 Machine Maintenance 3- 41
Emergency Stop Condition
Pressing the Emergency Stop button removes all servo power and power to the way
lubrication pumps. A message on the screen indicates the Emergency Stop condition, and
the red beacon lights up.
To restore machine power after an Emergency Stop condition:
1. Twist and lift the Emergency Stop Button.
2. Press these console keys in this order:
a. Press the Manual console key.
b. Press the Power On button. The Start Cycle button flashes.
c. Press the Start Cycle button to enable the servos.
Machine Diagnostics
The control detects the status of various machine components and presents this
information on the ATC & Machine Diagnostics screen.
To reach the ATC & Machine Diagnostics screen, follow these steps:
1. Press the Machine Mode Manual console key.
2. Select the DIAGNOSTICS F3 softkey.
3. Select the MACHINE DIAGNOSTICS F6 softkey.
If an error condition is displayed, follow these steps:
1. Follow the instructions on the MACHINE DIAGNOSTICS screen.
2. Once the error status is corrected, exit the MACHINE DIAGNOSTICS screen.
3. Restart and calibrate the machine.
There may be more than one Emergency Stop Button on your
machine. Know the location of each one.
Please refer to the Machine Diagnostics information in the WinMax
Mill On-screen Help for more details about machine and ATC
diagnostics for your machining center.
