1 - 12 Machine Components 704-0212-209 VM Series Maintenance and Safety Manual
Axes Motion System
AC servo drive systems power the X, Y, and Z axes, as well as the A, B, and C axes, if
equipped, in Hurco machining centers.
Axis Travel Dimensions
Machine axis travel dimensions appear in the tables below, in metric and English
measurements. If NA is indicated, the axis is not available for the machine model.
Table 1–11. Axis Maximum Travel, Metric
Table 1–12. Axis Maximum Travel, English
Machine
Maximum Travel
X-axis Y-axis Z-axis
VM5
457 mm 356 mm 356 mm
VM10
660 mm 406 mm 508 mm
VM10G
660 mm 406 mm 508 mm
VM10P
660 mm 406 mm 508 mm
VM10U
533 mm 406 mm 483 mm
VM20
1016 mm 508 mm 508 mm
VM30
1270 mm 508 mm 508 mm
Machine
Maximum Travel
X-axis Y-axis Z-axis
VM5
18 in 14 in 14 in
VM10
26 in 16 in 20 in
VM10G
26 in 16 in 20 in
VM10P
26 in 16 in 20 in
VM10U
21 in 16 in 19 in
VM20
40 in 20 in 20 in
VM30
50 in 20 in 20 in
