Hurco VM10 - Automatic Tool Changer

VM Series Maintenance and Safety Manual 704-0212-209 Machine Components 1- 35
Automatic Tool Changer
Each VM machining center is equipped with a swing-arm random pocket Automatic Tool
Changer (ATC). The tables below list tooling specifications in metric and English.
Table 1–21. ATC Tool Specifications, Metric
Table 1–22. ATC Tool Specifications, English
For information about the ATC and Machine Diagnostics, refer to the
on-screen Help or the Getting Started with Your WinMax Mill PDF file
that is available on the control’s hard drive.
Machine Taper
Number of
Tool
Pockets
Maximum
Tool
Diameter
Maximum
Tool
Diameter
Adjacent
Tool
Pockets
Empty
Maximum
Tool
Length
Maximum
Tool
Weight
VM5
40 16 89 mm 127 mm 200 mm 6.8 kg
VM10
40 20 89 mm 127 mm 250 mm 6.8 kg
VM10G
30 20 60 mm 100 mm 250 mm 5.0 kg
VM10P
30 20 66 mm 75 mm 250 mm 3.0 kg
VM10U
40 20 89 mm 127 mm 250 mm 6.8 kg
VM20
40 20 89 mm 127 mm 250 mm 6.8 kg
VM30
40 20 89 mm 127 mm 250 mm 6.8 kg
Machine Taper
Number of
Tool
Pockets
Maximum
Tool
Diameter
Maximum
Tool
Diameter
Adjacent
Tool
Pockets
Empty
Maximum
Tool
Length
Maximum
Tool
Weight
VM5
40 16 3.5 in 5.0 in 7.9 in 15.5 lbs
VM10
40 20 3.5 in 5.0 in 9.8 in 15.5 lbs
VM10G
30 20 2.4 in 3.9 in 9.8 in 11.0 lbs
VM10P
30 20 2.6 in 3.0 in 9.8 in 6.6 lbs
VM10U
40 20 3.5 in 5.0 in 9.8 in 15.5 lbs
VM20
40 20 3.5 in 5.0 in 9.8 in 15.0 lbs
VM30
40 20 3.5 in 5.0 in 9.8 in 15.0 lbs
