1 - 32 Machine Components 704-0212-209 VM Series Maintenance and Safety Manual
QWERTY Keyboard Port
A 6-pin mini-DIN female PS2 style keyboard connector is mounted to the rear of the
dual-screen console. On the Max control the connector is located under the console. Each
connects to the host computer via the Control Interface Harness in the pendant arm (or
overarm). An optional external QWERTY keyboard with protective cover and mounting
provision is available for each dual-screen and Max control. Information about options is
available from Hurco or your Hurco full-service distributor.
Coolant System
The flood coolant system pumps coolant to the tool in the spindle, cleans swarf from the
cut, and protects the part and tool. A washdown spray gun is externally mounted on the
machine to spray chips found inside the enclosure. The washdown spray gun may be an
option on some machine models.
The system is self-contained. The operator can control the coolant system using console
keys. See the Machine Maintenance chapter of this manual for more information on these
systems, and on selecting coolant.
The VM10G requires the use of a spindle oil chilling system rather than the flood coolant
system described here. Refer to the manufacturer’s handbook for more information on
the use and operation of the spindle oil chiller.
The following tables list coolant tank, pump, and wash down specifications, in metric and
English measurements.
Table 1–17. Coolant Capacity and Pump Rating, Metric
Table 1–18. Coolant Capacity and Pump Rating, English
If using a QWERTY keyboard, it must be connected prior to powering
on the machine.
Machine Tank Capacity Flood Pump Rating
VM5 62 liter 60 liter/min
VM10 62 liter 60 liter/min
VM10P 62 liter 60 liter/min
VM10U 62 liter 60 liter/min
VM20 122 liter 60 liter/min
VM30 122 liter 60 liter/min
Machine Tank Capacity Flood Pump Rating
VM5 16.3 gal 15.8 gal/min
VM10 16.3 gal 15.8 gal/min
VM10P 16.3 gal 15.8 gal/min
VM10U 16.3 gal 15.8 gal/min
VM20 32.0 gal 15.8 gal/min
VM30 32.0 gal 15.8 gal/min
