VM Series Maintenance and Safety Manual 704-0212-209 Machine Components 1- 31
Remote Jog Unit
Standard dual-screen controls have a Remote Jog Unit that interfaces to the host
computer via CANbus. It is powered by 12VDC via the Flat Panel Node. Features include
• Emergency Stop button
• Store Position console key
• Manual Pulse Generator (MPG) x1, x10, and x100 rate selections.
• 100 position MPG Handwheel
•Rapid +/- console keys
• Rapid Feed control knob
• Axis selector switch
The Remote Jog Unit may be equipped with an Enable button.
LCD Remote Jog Unit
The optional LCD Remote Jog Unit features include interfaces to the host computer via
CANbus. It is powered by 12VDC via the Flat Panel Node. Features include:
• Motion Hold button
• Stop Cycle button
• Emergency Stop button
• Enable button
• Store Position key
• LCD screen with Mode Selector buttons
• Jog Hand Wheel
• Jog Feed Keys
• Manual Pulse Generator (MPG) x1, x10, and x100 rate selections
• Jog Feed Override
• Axis Select Switch
Please refer to the WinMax Mill Help for details about operating the
Remote Jog Unit and the LCD Remote Jog Unit.
