1 - 4 Machine Components 704-0212-209 VM Series Maintenance and Safety Manual
Machine Table Specifications
The following tables list additional table specifications, in metric and English.
Table 1–3. VM Machine Table Specifications, Metric
Table 1–4. VM Machine Table Specifications, English
Head
The cast iron head assembly is designed to produce superior cutting accuracy. Each
machine has a vertical spindle and uses a motor brake for the Z axis.
Guideways
The axes guideways are precision linear rails.
Table 1–5. VMX Machine Guideways
Machine
Floor to Table
Surface
Working Surface Load Capacity
VM5 825 mm 457 mm x 356 mm 227 kg
VM10 851 mm 762 mm x 406 mm 340 kg
VM10G 851 mm 762 mm x 356 mm 340 kg
VM10P 851 mm 762 mm x 406 mm 340 kg
VM10U
largest part size
1076 mm 198 mm Diameter
320 mm Diameter x 254 mm
150 kg
VM20 910 mm 1168 mm x 508 mm 544 kg
VM30 910 mm 1321 mm x 508 mm 544 kg
Machine
Floor to Table
Surface
Working Surface Load Capacity
VM5 32.5 in 18 in x 14 in 500 lb
VM10 33.5 in 30 in x 16 in 750 lbs
VM10G 33.5 in 30 in x 14 in 750 lbs
VM10P 33.5 in 30 in x 16 in 750 lbs
VM10U
largest part size
42.4 in 7.8 in Diameter
12.6 in Diameter x 10 in
330 lbs
VM20 35.8 in 46 in x 20 in 1200 lbs
VM30 35.8 in 52 in x 20 in 1200 lbs
Machine Axis Way Type
VM5
X, Y and Z
(oil lubrication)
Linear, size 25 standard block
VM10
VM10G
VM10P
VM10U
X and Y
Z
(oil lubrication)
Linear, size 30 standard block
Linear, size 35 standard block
VM20
VM30
X and Y
Z
(oil lubrication)
Linear, size 35 standard block
Linear, size 45 standard block
