VM Series Maintenance and Safety Manual 704-0212-209 Operation Requirements 2- 7
CE Requirements
In order to comply with the CE Safety Requirements for machines sold in Europe,
machine operations meet the directives and standards listed in the “Machine Standards”
chapter of the CE Safety Manual for Machining Centers.
ANSI Standards
In order to comply with the American National Standards Institute (ANSI
®
) for machines
sold in the US, machine operations meet the accredited procedures listed in the ANSI
B11.23-2992 (R2007), titled “Safety Requirements for Machining Centers and Automatic,
Numerically Controlled Milling, Drilling and Boring Machines.”
Operation Requirements
Hurco machine tools are equipped with door interlocks to ensure the enclosure doors do
not open during machining operations. Periodically check the safety circuits, especially
after changing components. Basic mode operations are listed below.
Manual Mode Operations, Enclosure Doors Open
• Cannot park the machine or home the axes.
• Cannot warm up the machine.
• Cannot begin machine calibration cycle.
• Cannot start chip auger or conveyor.
• Cannot perform coolant functions except for washdown gun.
• Cannot perform ATC Diagnostics.
• Cannot begin an automatic tool change cycle.
• Cannot select the x100 multiplier on the Console Jog.
• Cannot run a part program in Auto mode.
Pressing the Emergency Stop button will lock the enclosure doors.
You may access the Auto (Conversational) screen and select the Run
Part Program F8 softkey. The Start Cycle button flashes. When you
press Start Cycle at this point, a message appears: “Cannot Start
Cycle with Guard Door open.” Press the OK screen button to
continue. At this point, you can shut the door and press Start Cycle
to run the program.
You may select the Auto console key and access Auto
(Conversational) screen to perform Estimated Run Time or Check for
Errors regardless of door status.
