6 CONTROLS

6.7 Plug-in stand

402581-10

The fixture for plug-in stand

is located on the frame on the

left side of the vehicle.

The plug-in stand is used to park the motorcycle.

Info

Remove the plug-in stand before riding.

6.8 Diagnostics connector

H03809-01

Diagnostics connector

is located under the seat.
