Husqvarna EE 5 2021 - Adjusting the Steering Head Bearing Play; Lubricating the Steering Head Bearing

13 SERVICE WORK ON THE CHASSIS
52
It must be possible to move the handlebar easily over the
entire steering range. There should be no detectable detent
positions.
» If detent positions are detected:
– Adjust the steering head bearing play. ( p. 52)
– Check the steering head bearing and replace if
required.
Finishing work
– Remove the motorcycle from the lift stand. ( p. 45)
13.12 Adjusting the steering head bearing play
Preparatory work
– Raise the motorcycle with a lift stand. ( p. 45)
M01718-10
Main work
–
Loosen screws
1
.
–
Loosen screw
2
.
–
Loosen and retighten nut
3
.
Guideline
Nut, steering head M20x1.5 10 Nm (7.4 lbf ft)
– Using a plastic hammer, tap lightly on the upper triple clamp
to avoid stresses.
–
Tighten screw
2
.
Guideline
Screw, top triple
clamp
M8 20 Nm (14.8 lbf ft)
–
Tighten screws
1
.
Guideline
Screw, top triple
clamp
M8 20 Nm (14.8 lbf ft)
Finishing work
– Check the steering head bearing play. ( p. 51)
– Remove the motorcycle from the lift stand. ( p. 45)
13.13 Lubricating the steering head bearing
H02387-01
– Remove the lower triple clamp. ( p. 48)
– Install the lower triple clamp. ( p. 49)
Info
The steering head bearing is cleaned and lubricated
in the course of removal and installation of the lower
triple clamp.
