2.3
EMERGENCY STOP:
• This button will stop both the hydraulic and blade motors. The head motion will cease. The vises
remain as they are, but if closed, they will lose gripping force. For this reason all long stock should be
supported so that it will not fall.
• To reset the button, simply rotate through 45º
RESET:
• This is used at the initialization phase after the “ON” button (machine start) is depressed and to RE-
SET any alarm conditions that may occur.
F1
F2
F3
F4
F5
F6
F7
F8
BLADE SPEED DIAL:
• This dial controls the blade speed which can be adjusted to the desired speed in SFM or SMM .
The blade speed is displayed on the LCD as “S”.
SHUTTLE
HOME
SHUTTLE HOME “F5”:
• This button is used to home the shuttle. It must be used in the start up sequence of the machine.
