Hyd-Mech V-18 - Page 100

Pg 7.3 V18 2001 a
CHIP CONVEYOR, parts list
ITEM QTY V-18 PART NUMBER DESCRIPTION
1
1 V18-12-01A CHIP CONVEYOR DRIVE SHAFT
2
4 40BS13HT CHAIN SPROCKET
3
2 V18-123-02 NUT
4
4 CJS 1612 FIBERGLIDE BUSHING
5
2 V18-123-01 DRIVE SHAFT BUSHING
6
1 H12-0102-01A MOTOR MOUNTING BUSHING
7
2 S1-.312x.5C SOCKET SET SCREW, CUP POINT
8
1 V18-12-02D CRANK EXTENSION
9
1 A1-.375x2.5 SOCKET HEAD CAP SCREW
10
2 .375LOC LOCK WASHER
11
2 .375HXNUT HEX NUT
12
1 V18-12-03 CRANK
13
1 CL-20-PH HANDLE
14
1 A1-.375x3.5 SOCKET HEAD CAP SCREW
15
8 V18-12-07A CHAIN RETAINER
16
16 A1-.25x.5 SOCKET HEAD CAP SCREW
17
1 V18-12-08 CHIP CONVEYOR PADDLE
18
2 V18-12-06 CONNECTING LINK
19
8 A1-.19x.5 SOCKET HEAD CAP SCREW
20
2 B1-.5x3 HEX HEAD CAP SCREW
21
2 SH-100 ST EXTERNAL SNAP RING
22
2 V18-124-00 IDLER ECCENTRIC SHAFT WELDMENT
23
2 V18-12-05 ECCENTRIC SHAFT WASHER
24
2 .5FLT FLAT WASHER
25
2 .5LOC LOCK WASHER
26
2 .5HXNUT HEX NUT
27
2 TRC 40 RIV CHAIN, 116.5" (295.9cm) each side
28
1 RS08010100 HYDRAULIC MOTOR
29
2 A1-.375x1 SOCKET HEAD CAP SCREW
30
2 2503-6-4 ADAPTOR
31
2 2103-4-4 90 DEGREE ELBOW
32
1 V18-12-04 TORQUE ARM
33
3 V18-12-11 SHAFT KEY
