ITEM QTY V18 PART NUMBER DESCRIPTION
1
1 V18-21-00G CARRIAGE FRAME WELDMENT
2
2 Z-HMS 9.678TFE WEAR RING
3
1 V18-2-01A PIVOT THRUST WASHER, FRONT
4
2 V18-2-02 PIVOT THRUST WASHER, REAR
5
1 V18-22-01D PIVOT SHAFT LUG, REAR
6
1 .875LOC LOCK WASHER
7
1 B1-.875x2 HEX HEAD CAP SCREW
8
2 1605-404-31, 1410 GUIDE RAIL
9
4 1653-414-10 RUNNER BLOCK
10
26 A2-.5x1.5 SOCKET HEAD CAP SCREW, NF
11
16 A1-.375x1 SOCKET HEAD CAP SCREW, NF
12
1 V18-23-00C STRUT WELDMENT
13
2 B1-.5x1 HEX HEAD CAP SCREW
14
2 .5LOC LOCK WASHER
15
2 B1-.625x1 HEX HEAD CAP SCREW
16
2 .625LOC LOCK WASHER
17
1 V18-C4-00 HEAD CYLINDER
18
2 CM-10 5/8 ROD END
19
2 5/8-18JNUT HEX JAM NUT, NF
20
1 B1-.625x2.25 HEX HEAD CAP SCREW
21
1 .625LOC LOCK WASHER
22
1 .625HXNUT HEX NUT
23
2 S1-.625x1 SOCKET SET SCREW, CUP POINT
24
2 V18-1-15B RAIL LOCATING PIN
25
1 .312HXNUT HEX NUT
26
1 V18-77-00 CONDUIT SUPPORT RING
